DESCRIPTION

• Supports 2 SIP profiles and 2 FXS ports
• Strong AES encryption with security certificate per unit
• Automated & secure provisioning options using TR069
• 3-way voice conferencing per port
• Exceptional voice quality with wide-band HD codec
• Supports T. 38 Fax for reliable Fax-over-IP
• Supports dual Gigabit network ports
• High performance NAT router

DATASHEET: Telephone InterfacesTwo (2) FXS portsNetwork InterfacesTwo (2) 10/100/1000Mbps RJ45 portsLED IndicatorsPOWER, LAN, WAN, PHONE1, PHONE2Factory Reset ButtonYesTelephony FeaturesCaller ID display or block, call waiting, flash, blind or attended transfer, forward, hold, do not disturb, 3-way conferenceVoice CodecsG. 711 with Annex I (PLC) and Annex II (VAD/CNG), G. 723.1, G. 729A/B, G. 726, iLBC, OPUS, dynamic jitter buffer, advanced line echo cancellationFax Over IPT. 38 compliant Group 3 Fax Relay up to 14.4kpbs and auto-switch to G. 711 for Fax Pass-throughShort/Long Haul Ring Load3 REN, up to 1km on 24AWG lineCaller IDBellcore Type 1 & 2, ETSI, BT, NTT, and DTMF-based CIDDisconnect MethodsBusy Tone, Polarity Reversal/Wink, Loop CurrentNetwork ProtocolsTCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS, DHCP, NTP, TFTP, TELNET, STUN, SIP (RFC3261), SIP over TCP/TLS, SRTP, TR-069QoSLayer 2 (802.1Q VLAN, SIP/RTP 802.1p) and Layer 3 (ToS, Diffserv, MPLS)DTMF MethodIn-audio, RFC2833 and/or SIP INFOProvisioning and ControlHTTP, HTTPS, TELNET, TFTP, TR-069 , secure and automated provisioning using AES encryption, syslogMediaSRTPControlTLS/SIPS/HTTPSMana gementSyslog support, telnet, remote management using web broswerUniversal Power SupplyInput: 100-240VAC, 50-60Hz Output: 12V/0.5AEnvironmentalOperational: 32º - 104ºF or 0º - 40ºC
Storage: 14º - 140ºF or -10º - 60ºC
Humidity: 10 - 90% Non-condensingDimension and Weight28.5 x 130 x 90 mm (H x W x D) Weight: 353.33gComplianceFCC/CE/RCM
